M100 Electric Mountain Bike
Motor
Hub Motor 250W, 50NM
Battery
Removable battery 375Wh
Max Battery Range
35 miles
M100 Electric Mountain Bike
In-depth information
Featuring a mighty 250W high performance motor and a 50Nm torque. Whether you're navigating city streets or tackling challenging terrain, our motors deliver a smooth, powerful ride every time.
Discover the unstoppable cruising with our high-capacity Lithium 36V, 10.4 Ah battery. effortlessly removable for recharging. This power source promises an impressive range of 35 Miles on a single charge.
Easy-to-read display monitors your speed, pedal-assistant level, mileage, battery status, etc.
Ride Into a Greener Future
What's in your box?
· ESKUTE M100
· Tool Box
· Charger
· Battery Key
| Top Speed | 15.5mph(*The motor will stop giving assist at the stated top speed. You can still ride beyond the stated top speed with pure muscle power.) |
| Range | Up to 35 miles on Pedal Assist |
| Weight Capacity | 125 KG |
| Recommended Rider Heights | 5'5"- 6'2" |
| Motor | 250W, 36V Brushless Rear Hub Motor, 42NM |
| Battery | Removable Lithium-ion 36V, 10.4Ah (375Wh) |
| Charger | 42V 2Amp, 5-6 Hour Charging |
| Sensor | Speed Sensor |
| Throttle | No Throttle included |
| Pedal Assist | 5 Levels |
| Display | Smart LED Display |
| Lights | Standard Eskute LED headlight |
| Frame | Carbon Steel |
| Front Fork | Suspension Fork with 100mm travel, with lockout |
| Brake | Mechanical Disc Brakes, 160mm Rotors |
| Tires | 27.5" x 1.95" |
|
Rims
|
Single Wall Aluminum 36h Front & Rear
|
| Crankset | 170mm w/ 44 T |
| Shift lever | SHIMANO 7 Speed |
| Pedals | 9/16' Alloy Platform |
| Chain | 7 Speed |
| Total Bike Weight | 52lbs |
| Battery Weight | 6lbs 3oz | Package Weight | 69lbs |
M100 is not recommended for frequent riding in the rain, especially during heavy rainfall.
If you must ride in the rain, please take the following steps to protect your bike and prevent damage to the battery:
-1.Remove the battery and allow the moisture to air dry.
-2.Clean and wipe dry the battery base to ensure it remains dry.
-3.Reinstall the battery only after both the battery and the battery base areas are completely dry.
Additionally, it is best to store your e-bike in a dry indoor environment. Long-term exposure to a damp outdoor environment can lead to oxidation of the battery mount, which may affect the lifespan of your e-bike.
Warning:
If you do not remove and clean the battery after riding in the rain, moisture can accumulate in the battery mount, which may cause oxidation of the battery terminals. This could result in permanent damage to the battery.
Disclaimer:
Battery issues caused by improper cleaning after riding in the rain or by frequent rain exposure are not covered under the ESKUTE battery warranty.
ESKUTE reserves the right to the final interpretation of this policy.
Thank you for your understanding and cooperation.
During the one-year warranty period, if the battery is found to be defective, it will be replaced at no charge to you. After the warranty period or if you need additional batteries, they can be purchased at Eskute
Not charging for 3 months will lead to battery damage, and the customer will be responsible for any damage to the battery caused by not charging for a long time. In order to keep the battery longer life, please keep charging at least once a half month.
Yes, for sure.
It can run around up to 60 KM on Pedal Assist ,Of course, the range for a single battery charge can vary greatly depending on conditions such as the combined weight of the rider and ebike, wind resistance, tyre pressure and tread profile, terrain and elevation changes, road or trail surface, outdoor temperature, maintenance of the E-Bike and the condition of the battery.
How to install
A useful guide to making the most of it all.
